PS-0338 is a black silicone elastomer that has been cast between two nonremovable polyester sheets. A removable protective blue film has been added to each side of the polyester film multilaminate.
General Industrial
PS-0338
• Converter Friendly
• Excellent Dielectric Strength
• Good Dimensional Stability
• Excellent Dielectric Strength
• Good Dimensional Stability
| Property | Value | Test Method |
|---|---|---|
| Available Thicknesses | 0.07mm-0.35mm | QSP-726 |
| Thickness Tolerance | +/- 15% | -- |
| Color | Black | -- |
| Hardness (Shore A) | 70 | ASTM D2240 |
| Dielectric Breakdown Strength | >2.5 kV/mm | ASTM D149 |
| Specific Gravity | 1.2 | ASTM D792 |
| Tensile Strength | 34.5 MPa (TD) 28.0 MPa (CD) | ASTM D412 |
| Elongation at Break | 46.6% (TD) 44.4% (CD) | ASTM D412 |
| Continuous Use Conditions | -40 - 120 C | QSP-754 |
Specific tests should be performed by the end user to determine the product suitability for the particular application.
