P-SHIELD® PS-1753 is a single coated, electrically conductive fabric with an electrically conductive pressure sensitive adhesive providing conductivity in the x, y and z-plane.
P-SHIELD®
PS-1753
Excellent Conformability
Excellent Adhesion to Low Energy Substrates
Good Shielding Effectiveness Over a Wide Frequency Range
RoHS and HF Compliant
Excellent Adhesion to Low Energy Substrates
Good Shielding Effectiveness Over a Wide Frequency Range
RoHS and HF Compliant
| Property | Value | Test Method |
|---|---|---|
| Continuous Use Conditions | -10 - 80 C | QSP-754 |
| Surface Resistivity (Adhesive) | <0.2 Ω/sq | QSP-741 |
| Acrylic Adhesion | >1500 g/25mm | QSP-722 |
| Color | Black | Visual |
| Total Thickness (excluding liners) | 0.055mm +/- 0.01mm | QSP-726 |
| Fabric Type | Woven | -- |
