P-SHIELD® PS-1774 with PET is an electro deposited copper foil which has been coated with an electrically
conductive adhesive on one side. A removable polyester protective film has been laminated to the copper to
reduce surface oxidation. This copper allows for electrical conductivity in the x, y and z-direction. PS-1774 with
PET utilizes a copper foil manufactured from 100% recycled copper.
P-SHIELD®
PS-1774 w/PET
• Superior Converting Properties
• Excellent Conformability
• Good Shielding Effectiveness
• RoHS and HF Compliant
• Excellent Conformability
• Good Shielding Effectiveness
• RoHS and HF Compliant
| Property | Value | Test Method |
|---|---|---|
| Total Thickness | 0.015mm, 0.035mm, 0.05mm, 0.065mm, 0.075mm, 0.085mm, 0.1mm, 0.13mm and 0.15mm +/- 10% | QSP-726 |
| Foil Type | Electrodeposited Copper | -- |
| Color | Copper | -- |
| Adhesive Peel Strength (to SUS) | >1000 g/25mm (≤0.12mm) 400 g/25mm (≥0.13mm) | QSP-722 |
| Surface Resistance (Adhesive) | <0.2 Ω/sq | QSP-741 |
| Z-Axis Resistance | <0.2 Ω/in2 | QSP-741 |
| Shielding Effectiveness (30 MHz - 1.5 GHz) | 80 - 100 dB | ASTM D4935 |
| Recommended Application Specification | 2 kg/square inch pressure for 2 seconds | -- |
| Continuous use Conditions | 15 - 70 C | QSP-754 |
Specific tests should be performed by the end user to determine the product suitability for the particular application.
