P-SHIELD® PS-2757 is an electrically conductive acrylic pressure sensitive adhesive to allow conductivity in the x, y and z-plane.
P-SHIELD®
PS-2757
• Superior Converting Properties
• Excellent Conformability
• Good Tack
• Good Adhesion to Low Surface
Energy Substrates
• RoHS and HF Compliant
• Excellent Conformability
• Good Tack
• Good Adhesion to Low Surface
Energy Substrates
• RoHS and HF Compliant
| Property | Value | Test Method |
|---|---|---|
| Total Thickness | 0.015 mm ± 0.01 mm | QSP-726 |
| Surface Resistivity | <0.15 Ω/sq | QSP-741 |
| Z-Axis Resistance | <0.15 Ω/in2 | QSP-741 |
| Color | Gray | Visual |
| Adhesive Peel Strength (to SUS) | >600 g/25mm | QSP-722 |
| Recommended Application Specification | 2 kg/square inch for 2 seconds | -- |
| Continuous Use Conditions | -10 – 80 C | QSP-754 |
Specific tests should be performed by the end user to determine the product stability for the particular application.
